Home MAX PHOTONICS 20000W 20kW FIBER LASER SOURCE

MAX PHOTONICS 20000W 20kW FIBER LASER SOURCE

Sale price £48,000.00 GBP

Notify me when available

Register to receive a notification when this item comes back in stock.

Ask a question
Share

New Max Photonics 20kW Fiber Laser Source Replacement or Upgrade.

If upgrade please be aware you also need 20kW chiller to ccomplement source.



Mode of Operation CW/Modulated
Polarization Random
Power Tunability 10 to 100%
Wavelength 1080 ± 5 nm
Power Stability ±1 %
Laser Beam Quality, BPP
3.5 to 4.5 mm x mrad (100μmQBH)
5 to 6.5 mm x mrad (150μmQBH)
6.5 to 9 mm x mrad (200μmQBH)
Modulation Frequency ≤ 5kHz
Preview Red Light Power 200 μW

 FIBER DELIVERY SYSTEM
Interface QD LOE
Length 20m standard, other lengths optional
Diameter  150/200 μm
Bending Radius 200 mm

 ELECTRICAL RATINGS
Supply Voltage 400 (-15% to +10%) VAC 3-phase

 OTHER SPECIFICATIONS
Operating Temperature +10 to +40℃
Storage Temperature -10 to +60℃
Humidity 10 to 80%
Cooling Method Water Cooling
Cooling Medium Distilled water/ Glycol Antifreeze
Dimension 1050×1385×1658 mm
Weight 815(±5) kg



For stock please contact office
